RN12
Tray Fillers



The RN12 is a robust tray filler engineered to deliver excellent filling uniformity across all standard container formats, including polystyrene, thermoformed, and injection-molded trays.
Featuring the capacity to handle tall containers up to 220 mm in height, this machine is particularly suited for the production of forestry plants, root cuttings, transplanting, and seeding. It incorporates an adjustable internal rotor that allows operators to alter the final soil density in the cells, adapting the machine to diverse crop requirements.
For efficient daily operations, the RN12 is equipped with manual adjustment cranks for fast, self-centering tray configuration alongside a built-in total recovery system for excess soil. Built around a continuous feeding belt system, the RN12 operates reliably as an independent standalone unit or can be integrated directly into a larger, automated working line.
Technical Specs
Hopper capacity (standard): 600 litres.
Paddles shaft agitator.
Double chain soil elevator.
4 blades longitudinal rotor, with rotation reversing gear and adjustable speed.
Double auger spillway with motorized brush for tray cleaning.
Quick self-centring guide adjustment system.
Recycling system for exceeding soil.
Electric control panel start-stop, emergency and limit switch.
Available in left and right version.
The RN12 is a robust tray filler engineered to deliver excellent filling uniformity across all standard container formats, including polystyrene, thermoformed, and injection-molded trays.
Featuring the capacity to handle tall containers up to 220 mm in height, this machine is particularly suited for the production of forestry plants, root cuttings, transplanting, and seeding. It incorporates an adjustable internal rotor that allows operators to alter the final soil density in the cells, adapting the machine to diverse crop requirements.
For efficient daily operations, the RN12 is equipped with manual adjustment cranks for fast, self-centering tray configuration alongside a built-in total recovery system for excess soil. Built around a continuous feeding belt system, the RN12 operates reliably as an independent standalone unit or can be integrated directly into a larger, automated working line.
Technical Specs
Hopper capacity (standard): 600 litres.
Paddles shaft agitator.
Double chain soil elevator.
4 blades longitudinal rotor, with rotation reversing gear and adjustable speed.
Double auger spillway with motorized brush for tray cleaning.
Quick self-centring guide adjustment system.
Recycling system for exceeding soil.
Electric control panel start-stop, emergency and limit switch.
Available in left and right version.
